Three Phase Residential Energy Storage Inverters

S6-EH3P(3-12)K-H

5K2 / 6K2 / 8K2 / 10K2 / 3K / 4K / 5K / 6K / 8K / 10K / 12K

Product Introduction

S6 Solar inverter that can connect solar panels and a high voltage battery. This inverter will capture the solar during the day and provide power to your home loads and charge the battery. At night it will use the battery to satisfy your home loads.This will prevent you from using any power from the grid and save you from ever paying them a cent! Fight back with the new S6 solar hybrid inverter from Solis.

Technical Specifications

    S6-EH3P(3-12)K-H

    Input DC (PV side)

    Max. input voltage: 500VC

    MPPT voltage range: 100-450V (12K: 200 - 850V)

    MPPT number: 3/4

    Output AC (Back-up)

    Rated output power:
    5kW / 6kW / 8kW / 10kW / 3kW / 4kW / 5kW / 6kW / 8kW / 10kW / 12kW

    Rated output voltage: 3/N/PE, 380V / 400V

    Efficiency

    Max. efficiency: 95.50 - 97.90%

    General Data

    Ingress protection: IP66

Datasheet Download

Leading Features

Unique Advantages Leading Advantages

Supports up to 4 MPPTs, suitable for multi-orientation and occlusion, to improve power generation

Support max 6 pcs in parallel, expanding system capacity

Customizable battery backup level for uninterrupted power

PV only off grid mode, to reduce the initial investment cost

Ingress protection IP66, adapting to harsher outdoor environments

Supports PV input up to 160% of the inverter's rated DC power, maximising solar utilisation

Supports up to 21A PV input current, compatible with the latest high-power PV modules

160% overload for 60s in off-grid mode, ensuring stable startup of motors, water pumps and air conditioner

Seamless on/off-grid switching in under 10ms, guaranteeing uninterrupted power supply

Support three-phase unbalanced output, each phase supports output max. 50% rated inverter power

Support three-phase unbalanced output, each phase supports output max. 50% rated inverter power Supports existing PV grid-tie power connection for export control and off-grid use

Support grid side generator access, adapting to scenarios with insufficient power supplySolisCloud: Smart remote control, AI optimisation, and instant troubleshooting — all in one platform

Redefining C&I Storage

Downloads

Datasheet Certificate Installation Video Manual
S6-EH3P(3-10)K-ND-Global-Datasheet-V3.8 S6-EH3P12K-ND-Global-Datasheet-V3.8
CE_S6-EH3P(3-10)K-H-EU(-OD)_S6-EH3P(5-10)K2-H(-OD)_S6-EH3P7K-H-LV Certificate_EN_50549-1_EN_50549-10_S6-EH3P(3-10)K-H-EU(-OD)_S6-EH3P(5-10)K2-H(-OD)_EUR_V01 Certificate_EN_50549-1_TypeA_B_VDE_0124_S6-EH3P(3-10)K-H-EU(-PRO)(-OD)_S6-EH3P(5-10)K2-H(-OD)_EUR_V01 Certificate_EN_50549-1_EN_50549-10_S6-EH3P(5-12)K-H-EU(21A)_S6-EH3P(5-10)K2-H(21A)_EUR_V06 Certificate_EN_300328_EN_301489_EN_55011_IEC_61000-6-1(-2)(-3)(-4)_EN_62109_EN_62479_EN_62920_S6-EH3P(3-12)K-H-EU(21A)_S6-EH3P(5-10)K2-H(21A)_S6-EH3P7 Certificate_EN_IEC_IEC_61000-6-1(2,3,4)_EN_55011_IEC_EN_62920_CISPR_11_S6-EH3P(3-12)K-H-EU(21A)(-AU)_S6-EH3P(5-10)K2-H(21A)_S6-EH3P7K-H-LV_S6-EA3P(5-1) Certificate_IEC_61000-3-2(-3)(-11)(-12)_S6-EH3P(3-12)K-H-EU(21A)_S6-EH3P(5-10)K2-H(21A)_S6-EA3P(5-10)KAA-NV-ND-H_Flicker_harmonic_V04
S6-EH3P(3-12)K-H_Installation_Video_264 S6-EH3P12K-H(21A)
Manual_S6-EH3P(3-10)K-H-EU_EUR_V2.0 Manual_S6-EH3P(5-12)K-H-EU(21A)_EUR_V1.0
